LSY kauv ntsia hlau conveyor yog tsim los xa cov ntaub ntawv ntau ntawm ib qho mus rau lwm qhov. Lub kauv ntsia hlau conveyor muaj cov kauv ntsia hlau tig hauv lub raj cylindrical, cov kauv ntsia hlau thawb cov khoom rau pem hauv ntej thaum nws tig, thiab cov khoom tawm ntawm qhov kawg ntawm lub raj. LSY kauv ntsia hlau conveyor tuaj yeem txav cov ntaub ntawv hmoov lossis cov ntaub ntawv hauv ob qho tib si kab rov tav thiab ntawm qhov inclination mus txog 60 degree.
Technical Data
|
Qauv |
SIB 160 |
TSI 200 |
SIB 250 |
SIB 300 |
SIB 400 |
||
|
Ntsia Hlau Diameter (mm) |
163 |
185 |
237 |
285 |
362 |
||
|
Kev sib hloov ceev (r/min) |
308 |
260 |
200 |
170 |
170 |
||
|
Housing Txoj kab uas hla (mm) |
194 |
219 |
273 |
325 |
402 |
||
|
Max. Peev xwm (t / h) |
25 |
40 |
60 |
90 |
120 |
||
|
Max. Ntev (m) |
15 |
18 |
25 |
25 |
25 |
||
|
Lub kaum sab xis ua haujlwm (degree) |
0-60 |
||||||
|
Lub zog (kw) |
L Tsawg dua lossis sib npaug li 7m |
5.5 |
7.5 |
11 |
18.5 |
18.5 |
|
|
L>7m |
7.5 |
11 |
15 |
22 |
22 |
||
|
Tiv tauj cov khoom siv |
Q235, SUS304, SUS316L |
||||||
Kev sib xyaw
LSY kauv ntsia hlau conveyor yog tsim los ntawm ob peb yam tseem ceeb uas ua hauj lwm ua ke los tsim ib tug seamless thiab npaum cov ntaub ntawv tuav system.
Screw: Cov ntsia hlau yog cov khoom tseem ceeb ntawm cov khoom siv, uas muaj lub dav hlau helical uas tig mus rau hauv cov yeeb nkab cylindrical.
Cov yeeb nkab: Cov yeeb nkab yog ib lub raj cylindrical uas nyob ib puag ncig cov ntsia hlau thiab muab txoj hauv kev rau cov khoom thauj.
Lub cev muaj zog thiab Gearbox: Lub cev muaj zog thiab gearbox muab lub zog thiab lub zog tsim nyog los tig cov ntsia hlau thiab thauj cov khoom.
Bearings thiab Seals: Cov kabmob thiab cov ntsaws ruaj ruaj yog siv los txhawb thiab tiv thaiv cov ntsia hlau thaum nws tig hauv cov yeeb nkab.
